Revelis EVO-35-12

Power Supply Revelis logo Rated Power Output Voltage Warranty IP Rating

PFC Power Supply Revelis EVO-35

FEATURES

  • protections: short circuit / over load
  • built-in PFC filter and double isolation wiring
  • plastic housing with IP67 level
  • can be mounted on flammable surfaces, e.g. wood
  • cooling by free air convection
  • compliance with European standards and certificates
  • high reliability
  • dedicated to applications based on LED lighting used in the furniture and advertising industry
  • 5 years warranty

TECHNICAL SPECIFICATIONS

Output Voltage

12V DC

Rated Current

2.9 A

Rated Power

35 W

Output Voltage Tolerance

± 5%

Input Voltage Range

220~240V AC

Frequency Range

50~60 Hz

Efficienty

86%

AC Input Current

< 0.18 A

Protection

Short circuit | Over load

Working temperature

-25°C ÷ +50°C

Working humidity

10 ~ 85% RH non-condensing

Compliance with the LVD 2014/35/EU

EN 61347-1:2015-09/A1:2021-06, EN 61347-2-13:2015-04/A1:2017-07, EN 62493:2015-11/A1:2023-03

Compliance with the EMC 2014/30/EU

EN IEC 61000-3-2:2019-04/A1:2021-08, EN IEC 55015:2019-11/A11:2020-07

Compliance with the RoHS 3 2015/863

EN IEC 63000:2019-01

Dimensions

110 x 40 x 29.5 mm

Output cable length

2 x 343 mm

Weight

0.228 kg

IP Rating

IP67
