COB-384

[pb_row background="none" solid_color_value="#FFFFFF" solid_color_color="#ffffff" gradient_color="0% #FFFFFF,100% #000000" gradient_color_css="" gradient_direction="vertical" pattern="" repeat="full" image="" stretch="YES" position="center center" paralax="no" parallax_scroll="no" video_url="" autoplay="no" border_width_value_="0" border_style="solid" border_color="#000" width_value="" width_unit="%" div_padding="" div_padding_top="10" div_padding_bottom="10" div_padding_right="10" div_padding_left="10" css_suffix="" id_wrapper="" ][pb_column span="span12"][pb_heading tag="h1" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="70" font_style="bold" color="#000000" border_bottom_width_value_="0" border_bottom_style="solid" border_bottom_color="#000000" padding_bottom_value_="0" appearing_animation="0" ]COB-384[/pb_heading][/pb_column][/pb_row][pb_row background="none" solid_color_value="#FFFFFF" solid_color_color="#ffffff" gradient_color="0% #FFFFFF,100% #000000" gradient_color_css="" gradient_direction="vertical" pattern="" repeat="full" image="" stretch="none" position="center center" paralax="no" parallax_scroll="no" video_url="" autoplay="no" border_width_value_="0" border_style="solid" border_color="#000" width_value="" width_unit="%" div_padding="" div_padding_top="10" div_padding_bottom="10" div_padding_right="10" div_padding_left="10" css_suffix="" id_wrapper="" ][pb_column span="span12"][pb_divider el_title="Divider 6" div_border_width="1" div_border_style="solid" div_border_color="#E0DEDE" appearing_animation="0" ][/pb_divider][/pb_column][/pb_row][pb_row background="none" border_width_value_="0" border_style="solid" border_color="#000" width_unit="%" div_padding_top="0" div_padding_right="0" div_padding_bottom="0" div_padding_left="0" ][pb_column span="span12"][pb_text el_title="ICONS" width_unit="%" enable_dropcap="no" appearing_animation="0" ] [/pb_text][pb_divider el_title="Divider 7" div_border_width="1" div_border_style="solid" div_border_color="#E0DEDE" appearing_animation="0" ][/pb_divider][/pb_column][/pb_row][pb_row background="none" solid_color_value="#FFFFFF" solid_color_color="#ffffff" gradient_color="0% #FFFFFF,100% #000000" gradient_color_css="" gradient_direction="vertical" pattern="" repeat="full" image="" stretch="none" position="center center" paralax="no" parallax_scroll="no" video_url="" autoplay="no" border_width_value_="0" border_style="solid" border_color="#000" width_value="" width_unit="%" div_padding="" div_padding_top="10" div_padding_bottom="10" div_padding_right="10" div_padding_left="10" css_suffix="" id_wrapper="" ][pb_column span="span12"][pb_image el_title="LED Strip COB-384" image_file="images/produkty/tasmy/led-strip-cob-384.jpg" image_alt="LED Strip COB-384" image_size="fullsize" link_type="image" image_container_style="no-styling" image_alignment="center" appearing_animation="0" ][/pb_image][/pb_column][/pb_row][pb_row ][pb_column span="span12"][pb_heading el_title="TECHNICAL SPECIFICATION" tag="h2" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="36" font_style="inherit" color="#000000" border_bottom_style="solid" border_bottom_color="#000000" appearing_animation="0" ]TECHNICAL SPECIFICATION[/pb_heading][pb_divider div_border_width="1" div_border_style="solid" div_border_color="#E0DEDE" appearing_animation="0" ][/pb_divider][pb_table tb_style="table-default" appearing_animation="0" ][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Input voltage [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 12V DC [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Nominal power usage [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 10 W/m [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Max power section [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 5 m [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Colour rendering index [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] >90 [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Beam angle [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 180° [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Dimmable with PWM controller [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] YES [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Szerokość taśmy [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 5 mm [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Strip width [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 2.2 cm [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Reel length [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 5 m [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Type of diode [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] COB384 [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Density [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] 384 LED/m [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] PCB [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 2 oz [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Installation [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] double-sided adhesive tape + mounting glue [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Lifespan [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] ~50000 hours [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Working temperature [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] -20°C ÷ +40°C [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] IP rating [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] IP20 [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Compliance with standards [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] CE / RoHS / WEEE [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] Warranty [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 3 years [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][/pb_table][/pb_column][/pb_row][pb_row ][pb_column span="span12"][pb_heading el_title="POSSIBLE COLOURS" tag="h2" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="36" font_style="inherit" color="#000000" border_bottom_style="solid" border_bottom_color="#000000" appearing_animation="0" ]POSSIBLE COLOURS[/pb_heading][pb_divider div_border_width="1" div_border_style="solid" div_border_color="#E0DEDE" appearing_animation="0" ][/pb_divider][pb_table tb_style="table-hover" appearing_animation="0" ][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Light colour [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] CCT [K] [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Luminous flux [lm/m] [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Luminous efficacy [lm/W] [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="active" ] Energy class [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] WW [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 2700-3200 [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 1012 [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 105 [/pb_table_item][pb_table_item width_value="" width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] F [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] NW [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 3800-4200 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 937 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 98 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] F [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][pb_table_item tagname="tr_start" ][/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] WH [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 6000-6500 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 1011 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] 103 [/pb_table_item][pb_table_item width_type="%" tagname="td" rowspan="1" colspan="1" rowstyle="default" ] F [/pb_table_item][pb_table_item tagname="tr_end" ][/pb_table_item][/pb_table][pb_alert alert_style="alert-danger" alert_close="no" appearing_animation="0" ] Ask our sales team for details of available colours. [/pb_alert][/pb_column][/pb_row][pb_row background="none" solid_color_value="#FFFFFF" solid_color_color="#ffffff" gradient_color="0% #FFFFFF,100% #000000" gradient_color_css="" gradient_direction="vertical" pattern="" repeat="full" image="" stretch="none" position="center center" paralax="no" parallax_scroll="no" video_url="" autoplay="no" border_width_value_="0" border_style="solid" border_color="#000" width_value="" width_unit="%" div_padding="" div_padding_top="10" div_padding_bottom="10" div_padding_right="10" div_padding_left="10" css_suffix="" id_wrapper="" ][pb_column span="span12"][pb_heading el_title="DIMENSIONS" tag="h2" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="36" font_style="inherit" color="#000000" border_bottom_style="solid" border_bottom_color="#000000" appearing_animation="0" ]DIMENSIONS[/pb_heading][pb_divider div_border_width="1" div_border_style="solid" div_border_color="#e0dede" appearing_animation="0" ][/pb_divider][pb_image el_title="LED Strip COB-384 dimensions" image_file="images/produkty/tasmy/led-strip-cob-384-dimensions.jpg" image_alt="LED Strip COB-384 dimensions" image_size="fullsize" link_type="no_link" image_container_style="no-styling" image_alignment="center" appearing_animation="0" ][/pb_image][/pb_column][/pb_row][pb_row ][pb_column span="span12"][pb_heading el_title="CONNECTION DIAGRAM" tag="h2" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="36" font_style="inherit" color="#000000" border_bottom_style="solid" border_bottom_color="#000000" appearing_animation="0" ]CONNECTION DIAGRAM[/pb_heading][pb_divider div_border_width="1" div_border_style="solid" div_border_color="#e0dede" appearing_animation="0" ][/pb_divider][pb_image el_title="LED Strip COB-384 connection diagram" image_file="images/produkty/tasmy/led-strip-cob-384-connection-diagram.jpg" image_alt="LED Strip COB-384 connection diagram" image_size="fullsize" link_type="no_link" image_container_style="no-styling" image_alignment="center" appearing_animation="0" ][/pb_image][/pb_column][/pb_row][pb_row background="none" solid_color_value="#FFFFFF" solid_color_color="#ffffff" gradient_color="0% #FFFFFF,100% #000000" gradient_color_css="" gradient_direction="vertical" pattern="" repeat="full" image="" stretch="none" position="center center" paralax="no" parallax_scroll="no" video_url="" autoplay="no" border_width_value_="0" border_style="solid" border_color="#000" width_value="" width_unit="%" div_padding="" div_padding_top="10" div_padding_bottom="10" div_padding_right="10" div_padding_left="10" css_suffix="" id_wrapper="" ][pb_column span="span12"][pb_heading el_title="DOWNLOAD" tag="h2" text_align="inherit" font="custom" font_face_type="google fonts" font_face_value="Lato" font_size_value_="36" font_style="inherit" color="#000000" border_bottom_style="solid" border_bottom_color="#000000" appearing_animation="0" ]DOWNLOAD[/pb_heading][pb_divider div_border_width="1" div_border_style="solid" div_border_color="#E0DEDE" appearing_animation="0" ][/pb_divider][pb_button el_title="DATA SHEET" button_text="DATA SHEET" link_type="url" button_type_url="/download/specyfikacje/tasmy/led-strip-cob-384-data-sheet.pdf" open_in="new_browser" icon="fa-download" button_alignment="inherit" button_size="default" button_color="btn-default" appearing_animation="0" css_suffix="btn-more-link s1" ][/pb_button][pb_button el_title="EU DECLARATION OF CONFORMITY" button_text="EU DECLARATION OF CONFORMITY" link_type="url" button_type_url="/download/deklaracje/eu-declaration-of-conformity-led-strips.pdf" open_in="new_browser" icon="fa-book" button_alignment="inherit" button_size="default" button_color="btn-default" appearing_animation="0" css_suffix=" btn-more-link s1" ][/pb_button][/pb_column][/pb_row]

Input voltage	12V DC
Nominal power usage	10 W/m
Max power section	5 m
Colour rendering index	>90
Beam angle	180°
Dimmable with PWM controller	YES
Szerokość taśmy	5 mm
Strip width	2.2 cm
Reel length	5 m
Type of diode	COB384
Density	384 LED/m
PCB	2 oz
Installation	double-sided adhesive tape + mounting glue
Lifespan	~50000 hours
Working temperature	-20°C ÷ +40°C
IP rating	IP20
Compliance with standards	CE / RoHS / WEEE
Warranty	3 years

Light colour	CCT [K]	Luminous flux [lm/m]	Luminous efficacy [lm/W]	Energy class
WW	2700-3200	1012	105	F
NW	3800-4200	937	98	F
WH	6000-6500	1011	103	F
